Carding Machine DS-C80DD
DS-C80DD
기능 및 특성
- Vibrate Hopper Feeder
- Breast & Cylinder Roll
- Two Doffer & Condenser
제품 상세설명
Standard & Hopper Feeder Type
| Specifications | C80DD | C100DD |
|---|---|---|
| Working Width | 2000mm | 2500mm |
| Capacity | 230kg/Hr | 330kg/Hr |
Cross Direction & Hopper Feeder Scale Box Type
기능 및 특성
- Scale Box Hopper Feeder
- Breast & Cylinder Roll
- One Doffer & Roller Comb
- Inter Conveyor (Cross Direction)
- Feed & Cylinder Roll
- One Doffer & Roller Comb
| Specifications | C80DD | C100DD |
|---|---|---|
| Working Width | 2000mm | 2500mm |
| Capacity | 160kg/Hr | 210kg/Hr |
Two Cylinder & Automatic Measuring Hopper Type
기능 및 특성
- Automatic Measuring Hopper Feeder
- Two Cylinder Roll
- Two Doffer & Condenser
| Specifications | C80DST | C100DST |
|---|---|---|
| Working Width | 2000mm | 2500mm |
| Capacity | 270kg/Hr | 370kg/Hr |
Standard & VT Hopper Type
기능 및 특성
- Vibrate Vertical Hopper
- Breast & Cylinder Roll
- Two Doffer & Roller Comb
| Specifications | VT80 | VT100 |
|---|---|---|
| Working Width | 2000mm | 2500mm |
| Capacity | 350kg/Hr | 500kg/Hr |
Flat card Type
기능 및 특성
- Nose-Bar & Feed Roller
- Licker-in Roller
- Flat Bar & Cylinder Roller
- Doffer Roller & Section Pipe
- Combination Roller
| Specifications | CF60 | CF80 |
|---|---|---|
| Working Width | 1500mm | 2000mm |
| Capacity | 150kg/Hr | 200kg/Hr |
